How Stair Lifts Work
A stair lift is basically a chair that travels along and rail or track that is mounted to a stairway.
There is a motor within the base of the chair that is generally powered by a battery also within the base of the chair. The stair lift motor turns a gear that is meshed into a geared strip on the track or rail. When the gear turns the chair is moved along the geared strip. When the motor turns the gear the chair moves one direction, when the motor’s direction is reversed the chair moves the opposite way.
Call/Send switches are used to move the stair lift chair without anybody being on it. This is especially helpful if 2 individuals utilize the lift and the lift is at the opposite end of the track when a user wishes to utilize it. the user simply calls the lift to come to them using a call/send switch. Another use of call/send switch is to send out the lift away after use. Some individuals don’t like the appearance of the lift parked in the main living area of the home in and will send it to the opposite end when not in use. They just call it back when required.
Stair Lift Components
Although the design and style of stair lifts will vary between producers they all have some fundamental elements typical to them all:
Track or Rail – The stair lift track supports the chair, provides a system (generally a geared strip) to move the chair and guides it up and down the staircase just as a train track guides a train.
Track Overruns – Some stair lifts use the choice of an overrun at either the top of the track, bottom of the track or both. The function of a stair lift track overrun is to move the user far from the stairway to safely access or dismount the stair lift in a location where, if they fall, they will not fall on the stairs.
Power supply – While many stair lifts are battery operated today all model will require a power supply to either charge the battery or power the system directly in the case of non-battery powered systems. Non-battery powered stair lifts draw a lot of power and generally need a dedicated circuit.
Call/Send Controls – Call/Send controls are normally installed on the wall near each end of the stair lift track to offer a way for a user to call the chair to them or send it away when not needed. They can be either cordless or wired to the lift depending on the model.
Seat – The stair lift seat is simply a seat for the user to rest on while using the lift. Depending on the model it may rotate at the top and/or bottom of the track and will typically fold up out of the way when not in use.
Seat Belt – As in a vehicle the stair lift safety belt is intended to hold the user safely seated on the seat while the lift is in usage.
Foot Rest – The foot rest of the stair lift is a safety feature to prevent the the users feet from striking the steps while using the lift and a comfort function to support the user’s feet when resting on the seat. The foot rest will have switches constructed into them to stop the lift must it hit anything on the stairs and will turn up out of the way when the lift is not in use.
Motor – The motor that drives a stair lift chair along the track is found in the base of the seat.
Transmission – Since the motor turns at too expensive a speed to securely move the stair lift the track at type of transmission is used to reduce the speed while increasing the power offered.
Battery Charger – Battery powered stair lifts need to have a charger of some sort to keep the battery charged. The battery chargers are typically found under the track or near one end of the track. The charger works automatically with no action needed by the user.
Battery – The batteries used in stair lifts are fairly costly and found within the base of the seat near the motor. They will have to be replaced at some time but their life span is determined in years and thier replacement need to not be a big issue.
How To Measure For Your Stair Lift Installation
Measurement 1: Stand at the top of stairs and extend the tape measure down to the landing, letting it rest on edge of each tread. The tape must not droop or flex along the way. Record the distance from the edge of the upper landing to where the end of the measuring tape rests on the landing at the bottom of the stairs.
Measurement 2: Measure from the edge of the upper landing (like Measurement 1) to the edge of the very first stair’s tread at the bottom.
Measurement 3: Determine the width of your stair’s treads.
Measurement: Measure from the edge of the first stair at the bottom to the wall (or door), if there is one.
Measurement 5 through 7 Measurements 5-7: These are the tread measurements.
Measurement 8: Measure from the top step to the nearby door, wall or other obstruction at the top of the stairs.
The Advantages of Stair Lifts for Senior Citizens
Outside stair lift Limited movement is a problem for lots of seniors and an issue for their families. Seniors who wish to stay in their homes and stay independent can enhance their movement and remain safe by installing a stair lift.
A stair lift can transport you or a loved one securely from one floor to another in your home. A stair lift can offer a safe ways of transport so that you will not need to worry about the dangers of falling on the stairs. It is a specifically good option for a senior who lives alone.
3 Vital Uses for Heavy-Duty Stair Lift
Stair lifts come in a range of sizes and capacities. Compact models accommodate and offer movement for narrow staircases, supporting up to 350 pounds while doing so, and at the other end, heavy-duty stair lifts provide a broader seat and can manage a higher range of body types.
1. You Can Supply Access to Almost Everyone
Because of the larger, more powerful design, the stair lift provides availability and enhances movement for anybody who’s much heavier than average. Nevertheless, the normal stair lift might be too narrow or too short for some, and as the heavy-duty design offers a larger, greater seat, it further accommodates anyone who’s taller than average or has problem comfortably utilizing a basic design.
2. Industrial Applications
While not needed to satisfy ADA standards, stair lifts offer an added benefit to those with movement issues.
Within a home, a basic lift might accommodate 2 average-sized adults, however exactly what about when you need to deal with the general public? Your client base, clients, and patients likely been available in a series of shapes and sizes, so the sturdy model essentially suits everyone who would have to use the stairs.
Be aware that, to set up a heavy-duty lift, any staircase should supply 36 inches of space.
3. For Several Household Members
Exactly what happens, though, when several member of the family need availability? Whether you’re satisfying a current need or anticipating a future one, setting up a bigger lift takes everyone’s physical needs into consideration. If your house’s geared up with enough area, take preventative measures by having a heavy-duty lift installed.
